Siemens 6FC5203-0AF00-0AA0 | SINUMERIK OP 015A Operator Panel 15.1″

Product Overview
The Siemens 6FC5203-0AF00-0AA0 is an OP 015A (Operator Panel 015A) front unit for the SINUMERIK 840D powerline CNC system. This large-format operator panel features a 15.1-inch TFT color display with high resolution, providing superior visualization for complex CNC applications. The OP 015A is designed to be used with the PCU 50 or TCU as the central processing unit .

Technical Specifications

• Model Number: 6FC5203-0AF00-0AA0

• Product Type: OP 015A Operator Panel Front

• Product Line: SINUMERIK 840D powerline

• Display Size: 15.1 inch TFT

• Resolution: 1024 x 768 pixels (XGA)

• Input Method: Membrane keys

• Front Protection: IP65

• Rear Protection: IP00

• Power Consumption: Max 25 W

• Operating Voltage: Via PCU, TCU or video link receiver (5V DC)

• Operating Temperature: 0°C to 45°C (front)

• Storage Temperature: -20°C to 60°C

• Dimensions (W x H x D): 483 mm x 355 mm x 53 mm

• Depth without PCU: 42 mm

• Depth with PCU 50.3: 127 mm

• Weight: Approx. 8.4 kg

• Approvals: cULus

Key Features

• Large 15.1" TFT Display: 1024x768 resolution for clear visualization

• IP65 Front Protection: Dust-tight and protected against water jets

• Membrane Keypad: Industrial-grade keys for reliable operation

• Compact Depth: Only 42mm without PCU for space-saving installation

• cULus Certified: Meets North American safety standards

• Compatible with PCU 50: Complete HMI solution when paired with PCU 50

Typical Applications

• SINUMERIK 840D powerline CNC systems

• Complex machining centers

• High-end milling and turning machines

• Multi-axis CNC applications

• Industrial automation HMI stations

Compatibility Notes

• Designed to work with PCU 50 (e.g., 6FC5210-0DF31-2AA0)

• Can also operate with TCU (Thin Client Unit)

• Compatible with SINUMERIK 840DE powerline systems

What's Included

• 6FC5203-0AF00-0AA0 OP 015A operator panel front

• Mounting hardware

•
