Siemens 6FC5203-0AF03-0AA0 | SINUMERIK OP 015 Operator Panel 15″ TFT

6FC5203-0AF03-0AA0
Series: SINUMERIK Electronic Handwheel
Input: Manual Pulse Signal
Output: Position Control Signal
Rated Power: N/A
Rated Current: N/A
Protection Class: IP20
Applications: Practical handwheel for general machine tool positioning use

Band：Siemens
Condition: Brand new / Original
Stock: In stock
Delivery: 3 - 7 days
Warranty: 12 months

Product Overview
The Siemens 6FC5203-0AF03-0AA0 is an OP 015 (Operator Panel 015) front unit for SINUMERIK 840D powerline, 840D sl, and 810D powerline CNC systems . This operator panel features a 15-inch TFT color display with high resolution, providing comprehensive HMI functionality for machine tool control.

Technical Specifications

Parameter	Value
Model Number	6FC5203-0AF03-0AA0
Product Type	OP 015 Operator Panel
Series	SINUMERIK 840D / 810D powerline, 840D sl
Display Size	15.0 inch TFT
Resolution	1024 x 768 pixels (XGA)
Brightness	300 cd/m²
Contrast Ratio	500:1
Response Time	25 ms
Viewing Angle	160° horizontal, 140° vertical
Input Method	Membrane keys
Soft Keys	8 + 4 horizontal, 8 vertical
Ports	USB
Power Supply	Via PCU, TCU, or video link receiver (5V DC)
Power Consumption	Max 24 W
Front Protection	IP65
Rear Protection	IP00
Weight	3.63 - 8.0 kg (approx.)

Product Lifecycle Notice
⚠️ Siemens discontinued this product effective October 2017 . Available as a spare/replacement part only.

Key Features

15" TFT color display with 1024x768 XGA resolution
High brightness (300 cd/m²) for clear visibility
Membrane keypad with 8+4 horizontal and 8 vertical softkeys for flexible menu navigation
USB port for external connectivity
IP65 front protection - dust-tight and water jet resistant
Compatible with SINUMERIK 810D/840D powerline and 840D sl systems

Compatibility Notes
Compatible with the following SINUMERIK systems :

SINUMERIK 810D powerline / 840D powerline with PCU 20/PCU 50.3
SINUMERIK 840Di/840Di sl
SINUMERIK 840D sl with NCU 710.2/720.2/720.2 PN/730.2/730.2 PN and PCU 50.3

Accessories

USB port caps (set of 10): 6FC5248-0AF05-0AA0
Replacement parts: 6FC5248-0AF06-0AA0

Typical Applications

SINUMERIK 840D powerline CNC machine tools
SINUMERIK 810D powerline CNC systems
SINUMERIK 840D sl high-end CNC applications
Legacy CNC system maintenance and repair

What's Included

6FC5203-0AF03-0AA0 OP 015 operator panel
Mounting tension jacks (included in delivery)
