Siemens 6SL3000-1BE31-3AA0 | S120 Braking Resistor 510-720V DC

Product Overview
The Siemens 6SL3000-1BE31-3AA0 is a braking resistor for the SINAMICS S120 drive system. This component is designed to dissipate regenerative energy from the DC link during braking operations .

When the DC link voltage rises to the activation threshold, the braking unit is enabled, connecting the braking resistor to the DC bus to convert regenerative energy into heat .

Technical Specifications

• Model Number: 6SL3000-1BE31-3AA0

• Product Type: Braking Resistor

• Compatible Power Modules: PM340 with 380-480V 3AC input

• DC Link Voltage: 510-720V DC

• Product Lifecycle: PM300 - Active Product

Key Features

• Designed for SINAMICS S120 PM340 power modules

• Dissipates regenerative braking energy

• Protects DC link components from overvoltage

• Used when regenerative energy cannot be fed back to the grid

Typical Applications

• SINAMICS S120 PM340 drive systems requiring dynamic braking

• Applications with frequent deceleration cycles

• Vertical lifting and hoisting applications

• High-inertia load braking

Compatibility Notes

• Compatible with 380-480V 3AC PM340 power modules (DC link 510-720V)

• Each braking unit must be connected to its own braking resistor

• Cable length between braking unit and braking resistor should not exceed 10m

What's Included

• 6SL3000-1BE31-3AA0 braking resistor

• Mounting hardware

•
