Siemens 6SL3000-2BE32-1AA0 | SINAMICS Output Reactor 210A

Product Overview
The Siemens 6SL3000-2BE32-1AA0 is an output reactor (motor inductor) for the SINAMICS drive system. This component is suitable for Power Modules with 110kW rating and provides essential motor-side filtering.

Technical Specifications

• Model Number: 6SL3000-2BE32-1AA0

• Product Type: Output Reactor / Motor Inductor

• Nominal Current: 210 A

• Power Dissipation: 0.486 kW

• Suitable for Power Module: 110kW rating

• Input Voltage: 380-480V 3AC (-10%/+10%)

• Protection Class: IP00

• Connection to Power Module: Flat connector for M10 cable lug

• Connection to Motor: Flange connection for M10 cable lug

• PE Connection: M8 screw type

• Dimensions (W x H x D): 300mm x 285mm x 257mm

• Weight: 60 kg (132.28 lbs) / 77.11 kg

• Max Motor Cable Length (380-480V): Shielded - 300m, Unshielded - 450m

Key Features

• Reduces voltage reflection at motor terminals

• Limits capacitive charging currents in long cables

• Protects motor insulation from voltage spikes

• Enables motor cable lengths up to 300m (shielded) or 450m (unshielded)

Typical Applications

• SINAMICS S120 Power Modules 110kW

• SINAMICS G120 drive systems

• Long distance motor installations

• Multi-motor applications

Compatible Power Modules

• 6SL3310-1TE32-1AA0 (110kW Power Module)

What‘s Included

• 6SL3000-2BE32-1AA0 output reactor

• Mounting hardware

•
