Siemens 6SL3210-1SE23-2UA0 | S120 PM340 11kW Power Module

Product Overview
The Siemens 6SL3210-1SE23-2UA0 is a single-axis AC/AC power module from the SINAMICS S120 drive family. Part of the PM340 Booksize series, this unit delivers 11kW of output power at 32A, representing the upper range of the Framesize C (FSC) category .

This module is designed for demanding industrial applications requiring significant power output while maintaining the compact Booksize format. It offers high power density for applications where FSC frame size is the preferred choice.

Technical Specifications

• Model Number: 6SL3210-1SE23-2UA0

• Product Type: S120 PM340 Power Module (Booksize)

• Rated Power: 11.0 kW

• Input Voltage: 380-480V AC (3-phase)

• Rated Output Current: 32.0 A

• Operating Frequency: 50/60 Hz

• Frame Size: Framesize C (FSC) - Booksized

• Integrated Safety: Safe Torque Off (STO) according to EN 61800-5-2

• Braking Chopper: Built-in

• Cooling Type: Internal air cooling

• Protection Class: IP20

• Operating Temperature: 0°C to +40°C

• Dimensions: FSC standard dimensions

• Weight: Approx. 12.0-13.0 kg

What‘s Included

• 6SL3210-1SE23-2UA0 power module

• DRIVE-CLiQ cable

• Mounting screws and busbar covers

• Quick start guide

What You’ll Need Separately

• Line reactor: Required for this power class

• 24V DC power supply: 2.0A minimum

• Control unit: CU310-2 or CU320-2

Typical Applications for 6SL3210-1SE23-2UA0

This 11kW module is ideal for:

• Heavy-duty conveyor systems

• Large industrial mixers and agitators

• Extruders and injection molding machines

• Large palletizers and stackers

• Fan and pump drives up to 11kW

• Compressors and blowers

• Hoists and cranes

• Test stands and dynamometers

Comparison with Adjacent Models

Frequently Asked Questions

Q: What is the rated output current of 6SL3210-1SE23-2UA0?
A: The module provides 32.0A output current at 11kW power rating.

Q: What frame size does this module use?
A: This module uses Framesize C (FSC) / Booksized construction.

Q: Does this module include a braking chopper?
A: Yes, a built-in braking chopper is included.

Warranty & Shipping

• 12-month warranty on all products

• Free technical support

• 30-day returns for unused units

• Worldwide shipping available

•
