Siemens 6SL3210-1SE13-1UA0 | S120 PM340 1.1kW Power Module

Product Overview
The Siemens 6SL3210-1SE13-1UA0 is a single-axis AC/AC converter power module from the SINAMICS S120 drive family. Part of the PM340 Booksize series, this compact unit integrates both rectifier and inverter sections, delivering reliable power conversion for industrial applications requiring up to 1.1kW of output power .

This module represents the next step up from the 0.75kW variant, offering increased power while maintaining the same compact Framesize A (FSA) footprint. It is specifically designed for applications where higher torque is required but cabinet space remains constrained.

Technical Specifications

• Model Number: 6SL3210-1SE13-1UA0

• Product Type: S120 PM340 Power Module (Booksize)

• Rated Power: 1.1 kW

• Input Voltage: 380-480V AC (3-phase)

• Rated Output Current: 3.1 A

• Operating Frequency: 50/60 Hz

• Frame Size: Framesize A (FSA) - Blocksize

• Cooling Type: Internal air cooling

• Protection Class: IP20

• Operating Temperature: 0°C to +40°C

• Storage Temperature: -40°C to +70°C

• Dimensions: 73mm x 145mm x 173mm (W x D x H)

• Weight: Approx. 1.4 kg

What‘s Included

• 6SL3210-1SE13-1UA0 power module

• DRIVE-CLiQ cable

• Mounting screws and busbar covers

• Quick start guide

What You’ll Need Separately

• Line reactor: Recommended for this power class

• 24V DC power supply: 0.5A minimum

• Control unit: CU310-2 or CU320-2

Product Lifecycle Notice
Please note that Siemens has announced end-of-life for this model (effective October 1, 2019). This product is now available as a spare/replacement part only .

Typical Applications for 6SL3210-1SE13-1UA0

This 1.1kW module is ideal for:

• Standard conveyor systems (10-20 meters)

• Small packaging machines (form-fill-seal, cartoners)

• Small mixers and agitators with 1.1kW motors

• Light-duty palletizers

• Small extruders and injection molding auxiliary equipment

• Fan and pump drives up to 1.1kW

Why Choose the 1.1kW Model?

If you’re deciding between the 0.75kW (1SE12-2UA0) and the 1.1kW (1SE13-1UA0):

• Choose the 1.1kW if: Your motor is 1.1kW or you need extra headroom for load variations. This model offers approximately 45% more power than the 0.75kW version while maintaining the same FSA footprint.

• Choose the 0.75kW if: Your motor is 0.75kW or smaller and you don‘t anticipate load increases.

System Compatibility

Compatible with:

• CU310-2 PN (PROFINET)

• CU310-2 DP (PROFIBUS)

• CU320-2 PN (multi-axis setups)

• TIA Portal V15.1 and newer

• STARTER / SCOUT software

Comparison with Adjacent Models

Frequently Asked Questions

Q: What is the frame size of 6SL3210-1SE13-1UA0?
A: This module uses Framesize A (FSA) / Blocksize construction, the same compact footprint as the lower-power 0.37kW-0.75kW models.

Q: Is this product still in production?
A: Siemens has discontinued this model as of October 1, 2019. It is now available only as a spare or replacement part. We recommend verifying stock availability before ordering.

Q: What are the physical dimensions?
A: Width: 73mm, Height: 173mm, Depth: 145mm. Weight is approximately 1.4 kg .

Q: What cooling method does this module use?
A: Internal air cooling .

Warranty & Shipping

• 12-month warranty on all products

• Free technical support via email and phone

• 30-day returns for unused units

• Worldwide shipping available

•
